SULI drying equipment specializes in producing belt dryers for Mesh
Belt Drying Machine
Features of Multilayer Belt Dryer
1. The hot gas flow passes through the mesh belt and the material
layer from bottom to top, thus ensuring uniform heat transfer. This
drying machine has high production efficiency and good quality.
2. This multilayer conveyor dryer adopts hoisting equipment with
uniform feeder, and the thickness of the material layer can be
infinitely variable control.
The adapted materials
can satisfy the drying and mass production of vegetable materials
such as roots, stems, and leaves, blocks, flakes, and large
particles, and can also retain the nutrients and colors of the
products as much as possible.
Drying typical materials are: garlic slices, pumpkin, carrots,
konjac, yams, bamboo shoots, horseradish, onions, apples and so on.
Performance characteristics
Drying area, air pressure, air volume, drying temperature, belt
speed can be adjusted. To adapt to the characteristics of
vegetables and quality requirements.
According to the characteristics of the vegetables, different
technological processes can be used and necessary auxiliary
equipment can be added.
model | DWC1.6-I ( Loading table) | DWC1.6-II (middlestage) | DWC1.6-III (discharge table) | DWC2-I (loading station) | DWC2-II (middle stage) | DWC2-III (discharge table) |
Broadband (m) | 1.6 | 1.6 | 1.6 | 2 | 2 | 2 |
Drying section length (m) | 10 | 10 | 8 | 10 | 10 | 8 |
Material thickness (mm) | ≤100 | ≤100 | ≤100 | ≤100 | ≤100 | ≤100 |
Working temperature (°C) | 50-150 | 50-150 | 50-150 | 50-150 | 50-150 | 50-150 |
Heat transfer area (m 2 ) | 525 | 398 | 262.5 | 656 | 497 | 327.5 |
Steam pressure (Mpa) | 0.2-0.8 | 0.2-0.8 | 0.2-0.8 | 0.2-0.8 | 0.2-0.8 | 0.2-0.8 |
Drying time (h) | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 | 0.2-1.2 |
Transmission power (kw) | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 | 0.75 |
Overall size (m) | 12×1.81×1.9 | 12×1.81×1.9 | 12×1.81×1.9 | 12×2.4×1.92 | 12×2.4×1.92 | 10×2.4×1.92 |
Belt Dryer Pictures
![]() |
